Big End Bearing: 35x43x21.7 mm
Big End Bore: 43.00 mm
Big End Width: 21.90 mm
Center to Center: 129.00 mm
Pin Diameter: 35.00 mm
Pin Length: 64.60 mm
Small End Bore: 20.00 mm
Washer Thickness: 0.95 mm
KTM: 59030015044
Vehicle Fitments:
KTM 250 EXC (2003–2005)
KTM 250 XC (2003–2005)
KTM 250 XC-W (2003–2005)
KTM 450 EXC (2003–2007)
KTM 450 EXC-R (2003–2007)
KTM 450 MXC (2003–2005)
KTM 450 SX-F (2003–2004)
KTM 450 XC (2008)
KTM 450 XC-W (2007)
KTM 525 EXC (2003–2007)
KTM 525 MXC (2003–2007)
KTM 525 SMR (2003–2007)
KTM 525 SX (2003–2007)
KTM 525 XC (2003–2008)
KTM 540 SXS (2004)
Washer Thickness (mm):The double-forged construction optimizes grain flow and guarantees dimensional consistency, while shot peening and double-honing techniques significantly increase strength under heavy loads. Additionally, the small ends are double-drilled to improve lubrication and cooling for the wrist pin bearing, making it particularly suitable for pistons with crowns positioned close to the wrist pin....
To further enhance performance, thrust washers and crank pin bearings are silver-coated, providing superior lubricity. Each kit is comprehensive, including all necessary components for seamless installation, making it an ideal choice for high-performance applications.
